UL Power Distribution Box Phase Control Relay LS2

5380485
Interventional Image Guided Systems
IGS 3
GE Sistemas Médicos de México S.A. de C.V
GE HealthCare
Añadir a la lista de deseos
Iniciar sesión y agregar al carrito
Iniciar sesión y agregar al carrito
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


El artículo no está disponible en inventario con las cantidades seleccionadas. Por favor actualice la cantidad para continuar.

Características

  • 3-Phase monitoring relays for phase sequence and phase loss
  • Measure their own power supply
  • Detect when all 3 phases are present and have the correct sequence
  • 22.5 mm Euronorm housing

Descripción del producto

The UL Power Distribution Box Phase Control Relay LS2 is a 3-phase relay for detection of incorrect phase sequence, including total and partial phase loss. It has two multi-voltage relays to cover the supply voltage range from 208 to 690 VAC. It designed in such a way to be mounted on DIN-rail. The device detects regenerated voltages up to 85% of the nominal voltage (phase-phase). DPA01 series relays monitor their own 3-phase power supply. It operates only when all the phases are present and the phase sequence is correct, and releases when one phase-phase voltage drops below 85% of the other phase-phase voltages.

  • Características adicionales

    • LED indication for relay and power supply ON
